Serial Processing


Humdrum provides a handful of specialized tools for serial and serial-inspired analytic processing. In this chapter we introduce the reihe, pcset, iv, pf and nf commands These commands reveal their greatest power when used in conjunction with Humdrum tools we have already encountered -- such as context, humsed and patt.

The chapter culminates with a script that automatically identifies 12-tone row variants in complex orchestral scores. The general approach is instructive for applications beyond serial analysis.

Pitch-Class Representation

In set theoretic applications it is common to use pitch-class representations. The pc command can be used to transform pitch-related representations (such as **pitch, **freq and **kern) to a conventional pitch-class notation where pitch-class C is represented by the value zero. With the -a option, pc will generate outputs where the pc values `10' and `11' are rendered by the alphabetic characters `A' and `B' respectively. Using the alpha-numeric pc representation is recommended; it proves to be especially convenient for searching tasks since, otherwise, the characters 1 and 0 do not uniquely specify a single pitch-class type.

The pcset Command

A common set theoretic task is identifying occurrences of various pitch-class set forms. Figure 34.1 identifies the set forms for several sample vertical sonorities. These forms are identified using standard numerical designations (see Forte, 1973; Rahn, 1980). Set forms are insensitive to transposition, pitch-inversion, and pitch spelling so all major and minor triads are identified as pitch-class set 3-11. Similarly, the dominant seventh chord and `Tristan' chord are similarly related by inversion so both are identified as pc set 4-27.

Figure 34.1. Examples of PC set forms.

The
pcset command identifies pitch-class sets from **pc or **semits input. Illustrated below are the corresponding **kern, **pc and **pcset representations for Example 34.1.
**kern**pc**pcset
4c01-1
4c 4d0 22-2
4c 4e 4g0 4 73-11
4e 4g 4cc4 7 03-11
4g 4cc 4ee7 0 43-11
4c 4e- 4g0 3 73-11
4c 4e 4g 4b-0 4 7 104-27
4c# 4e# 4g# 4b1 5 8 114-27
4f 4b 4dd# 4gg#5 11 3 8 4-27
*-*-*-

Suppose we wanted to identify the pc sets for successive vertical sonorities in the first movement of Webern's Opus 24 concerto. First, we translate the input to a pitch-class representation, and then we apply the pcset command:

pc opus24 | pcset

Of course this command will only identify the set forms for pitches that have concurrent attacks. If any pitch is sustained, pcset won't know that some null tokens indicate sustained pitch activity. We can rectify this by using the ditto command (Chapter 15) to fill-out the null tokens:

pc opus24 | ditto -s ^= | pcset

If we wanted, we could assemble the resulting **pcset spine to the original input. This would allow us to search for particular patterns that are coordinated with certain pitch-class sets. For example, we might be interested in comparing the pitch-class sets that coincide with the beginnings of slurs/phrases versus those pitch-class sets coinciding with the ends of slurs/phrases. First we generate the **pcset spine:

pc opus24 | ditto -s ^= | pcset > opus24.pcs

Then we assemble this spine to the original input score:

assemble opus24 opus24.pcs > opus24.all

Now we can search for data records containing phrase (`{}') or slur ('()') markers. Using yank -m ... -r 0 rather than grep assures that the output retains the Humdrum syntax (see Chapter 12). Maintaining the Humdrum syntax will allow us to use extract to isolate just the **pcset data. Finally, we create an inventory of the pc sets. The process is repeated -- once for beginning slurs/phrases, and once for ends of slurs/phrases.

yank -m '[{(]' -r 0 opus24.all | extract -i '**pcset' \
| rid -GLId | sort | uniq -c
yank -m '[)}]' -r 0 opus24.all | extract -i '**pcset' \
| rid -GLId | sort | uniq -c

Two pitch-class set inventories will be generated: one inventory for the beginnings of phrases/slurs and one for phrase/slur endings.

Incidentally, the pcset command supports a -c option that can be used to generate the set complement rather than the principal set form.

Prime Form and Normal Form

The 3-11 set form designates both the major and minor chords (since they are symmetrical). In order to distinguish symmetrical forms, it is sometimes useful to represent pitch-class sets using either prime form (the pf command) or normal form (the nf command).

Suppose we wanted to count the proportion of phrase endings in music by Alban Berg where the phrase ends on either a major or minor chord. First, we locate all works composed by Berg:

BERG=`find /scores -type f -exec grep -l '!!!COM.*Berg,' "{}" ";"`

Let's put all the Berg works in a single temporary file:

cat $BERG > AllBerg

Next we generate the normal set forms:

pc AllBerg | ditto -s ^= | nf > AllBerg.nf

Assemble the **nf spine with the original scores:

assemble AllBerg AllBerg.nf > AllBerg.all

Now we're ready to count the number of phrases that match the appropriate patterns. First, count the total number of phrases:

grep -c '}' AllBerg.all

Count the number of phrases that end with a major chord:

grep -c '}.*\t(047)' AllBerg.all

And count the number of phrases that end with a minor chord:

grep -c '}.*\t(037)' AllBerg.all

Interval Vectors Using the iv Command

Interval vectors identify the frequency of occurrence of various interval-classes for a given pitch-class set. The iv command generates the six-element interval vector for any of several types of inputs -- including semitones (**semits), pitch-class (**pc), normal form (**nf), prime form (**pf), and pitch-class set (**pcset). The following example shows several different pitch-class sets, their corresponding pitch-class sets and (right-most spine), the associated interval vector.

**pc**pcset**name**iv
01-1tone<000000>
0 22-2major second<010000>
0 3 73-11minor triad<001110>
0 4 73-11major triad<001110>
0 4 7 104-27dominant seventh<012111>
1 5 8 114-27dominant seventh<012111>
*-*-*-*-

Suppose we wanted to determine whether Arnold Schoenberg tended to use simultaneities that have more semitone (interval-class 1) relations and fewer tritone (interval-class 6) relations. As before, we might translate his scores to pitch-class notation, fill-out the sonorities using ditto, and then determine the associated interval vectors for each sonority. Interval vectors without semitone relations will have a zero in the first vector position (i.e., <0.....>) whereas interval vectors without tritone relations will have a zero in the last position (i.e., <.....0>).

pc schoenberg* | ditto -s ^= | iv | grep -c '<0.....>'
pc schoenberg* | ditto -s ^= | iv | grep -c '<.....0>'

Segmentation Using the context Command

So far, we have processed only "vertical" sets of concurrent pitches. In set-theory analyses, there are many other important ways of "segmenting" the musical pitches into pitch-class sets. As we saw in Chapter 19, the context command provides a useful way of grouping together successive data tokens.

Suppose, for example, we wanted to analyze set forms in Claude Debussy's Syrinx for solo flute. The opening measures are shown in Example 34.1.

Example 34.1. From Claude Debussy, Syrinx for flute.

There are a number of ways we might want to try segmenting the melodic line. One possibility is to regard slurs or phrases as indicating appropriate groups. Recall that the -b and -e options for
context are used to specify regular expressions that match the beginning and end (respectively) of the context group: We can invoke an appropriate context command, translate the output to a pitch-class representation, and then use the pcset command to identify the set names:

context -b '[{(]' -e '[})]' syrinx | pc | pcset

Perhaps we might consider gathering groups of three successive notes together, and then generating an inventory of the set forms associated with such a segmentation:

context -n 3 -o '[=r]' syrinx | pc | pcset | rid -GLId \
| sort | uniq -c

Another possibility is to treat rests as segmentation boundaries.

context -e r syrinx | pc | pcset

When a work consists of more than one instrument or part, useful segmentations can be made by extracting each instrument individually, using context to generate musically-pertinent sets, and then assembling all of the **pcset spines into a single file.

The reihe Command

Twelve-tone music raises additional analysis issues. Variants of a tone-row can be generated using the reihe command. Given some input, reihe will output a user-specified transformation. Options are provided for prime transpositions (-P option), for inversions (-I option), for retrogrades (-R option) and for retrograde-inversions (-RI option).

Inputs do not have to be 12-tone rows. The 5-tone row used in Igor Stravinsky's "Dirge-Canons" from In Memoriam Dylan Thomas is as follows:

**pc
2
3
6
5
4
*-

The following command will generate a prime transposition of the tone-row so that it begins on pitch-class 6:

reihe -P 6 memoriam

The result is:

**pc
6
7
10
9
8
*-

Generating the inversion beginning at pitch-class 2 would be carried out using the following command.

reihe -a -I 2 memoriam

The -a option causes the values `10' and `11' to be rendered alphabetically as `A' and `B'.

The reihe command also provides a shift operation (-S) that is useful for shifting the serial order of data tokens forward or backward. Consider the following command:

reihe -S -1 memoriam

This shifts all of the data tokens back one position so the data begins with the second value in the input, and the first value is moved to the end:

**pc
3
6
5
4
2
*-

The shift option for reihe can be used to shift any type of data -- not just pitches of pitch-classes. For example, one might use the shift option to rotationally permute dynamic markings, text, durations, articulation marks, or any other type of Humdrum data. In Chapter 38 we will see how the shift option for reihe can be effectively used in many applications apart from serial analysis.

Generating a Set Matrix

The first step in automated row-finding is to generate a set matrix of all the set variants. Typically, the user begins with a hypothesized tone row. Suppose the tone-row was stored in a file called primerow. From this we can generate the entire set matrix. There is a Humdrum matrix command that automatically generates a set matrix, but let's create our own script to see how this can be done.

The following script uses the reihe command to generate each set form. Each form is stored in a separate file with names such as I8 and RI3. There are two noteworthy features to this script. Notice that the alphanumeric system (-a option) is used -- so the values `A' and `B' are used rather than `10' and `11'; this will facilitate searching. Also notice that our script provides an option that allows us to specify partial rows: that is, we can store (say) only the first 5 notes in each tone row file. This feature will also prove useful when doing an automatic search.


###################################################################
# MATRIX
# This script generates a tone-row matrix for a specified prime row.
# The -n option is used to specify the number of pitches to be out-
# put in each row-file (e.g. the first 7 pitches of a 12-tone row).
#
# Usage: matrix -n N primerowfile
#
if [ "x$1" != "x-n" ]
then
echo "-n option must be specified."
echo "USAGE: matrix -n number primerowfile"
exit
fi
if [ ! -f $3 ]
then
echo "File $3 not found."
echo "USAGE: matrix -n number row-file"
exit
fi
# Generate the primes, inversions, retrograde, etc:

X=0
while [ $X -ne 12 ]
do
reihe -a -P $X $3 | rid -GLId | head -$2 > P$X
reihe -a -I $X $3 | rid -GLId | head -$2 > I$X
reihe -a -R $X $3 | rid -GLId | head -$2 > R$X
reihe -a -RI $X $3 | rid -GLId | head -$2 > RI$X
let X=$X+1
done

For any given input, the above script produces 48 short files named P0, P1, ... I0, I1 ... R0, R1 ... RI10, RI11.

Locating and Identifying Tone-Rows

Each of the row variant files can be used as a template for the patt command (see Chapter 21). The following "rowfind" script shows how the Humdrum tools can be coordinated to carry out an automatic search and identification of tone row variants for some score.

The first part of the script simply checks to ensure that all of the row variant files are present:


###################################################################
# ROWFIND
#
# This script carries a preliminary tone-row search in a specified
# score. It assumes that a complete set of set-variant files exists
# in the current directory, named P0-P11, I0-I11, R0-R11, and RI0-RI11.
#
# This script puts a file named "analysis" which may be assembled
# with the original input file.
#
# Invoke:
# rowfind scorefile
#
# Check that the specified input file exists:
if [ ! -f $1 ]
then
echo "rowfind: ERROR: Input score file $1 not found."
exit
fi
# Also check that the row-variant files exist:
X=11
while [ $X -ne -1 ]
do
if [ ! -f P$X ]
then
echo "rowfind: ERROR: Row file P$X not found."
exit
fi
if [ ! -f I$X ]
then
echo "rowfind: ERROR: Row file I$X not found."
exit
fi
if [ ! -f R$X ]
then
echo "rowfind: ERROR: Row file R$X not found."
exit
fi
if [ ! -f RI$X ]
then
echo "rowfind: ERROR: Row file RI$X not found."
exit
fi
let X=$X-1
done

The following two lines of the script prepare the input score for searching. Specifically, the score is transformed to pitch-class notation (using pc) and then all rests are changed to null tokens using the humsed command. Notice the use of the -a option for pc in order to use the alpha-numeric pitch-class representation.

pc -at $1 > temp.pc
humsed 's/r/./g' temp.pc > score.tmp

The main searching task is done by patt. The patt command is executed 48 times -- once for each row variant. The -t (tag) option is used so that a **patt output is generated. Each time a match is made the appropriate name (e.g. P4) is output in the spine. The -s option is used to skip barlines and null data records when matching patterns. The -m option invokes the multi-record matching mode -- which allows patt to recognize row statements where several nominally successive pitches are collapsed into a vertical chord:

# Search for instances of each tone-row variant.
X=0
while [ $X -ne 12 ]
do

patt -s '=|^\.(\t\.)*$' -f P$X -m score.tmp -t P$X \

| extract -i '**patt' > P$X.pat

patt -s '=|^\.(\t\.)*$' -f I$X -m score.tmp -t I$X \

| extract -i '**patt' > I$X.pat

patt -s '=|^\.(\t\.)*$' -f R$X -m score.tmp -t R$X \

| extract -i '**patt' > R$X.pat

patt -s '=|^\.(\t\.)*$' -f RI$X -m score.tmp -t RI$X \

| extract -i '**patt' > RI$X.pat

let X=$X+1

done

Each of the above 48 patt searches resulted in a separate temporary output file. It would be convenient to reduce all 48 **patt spines into a single aggregate spine. This can be done using the assemble and cleave commands:

# Now we have a lot of files to assemble:
assemble P*.pat > prime.pat
cleave -d ' ' -i '**patt' -o '**rows' prime.pat > analysis.1

assemble I*.pat > inversion.pat
cleave -d ' ' -i '**patt' -o '**rows' inversion.pat > analysis.2

assemble R*.pat > retro.pat
cleave -d ' ' -i '**patt' -o '**rows' retro.pat > analysis.3

assemble RI*.pat > retroinv.pat
cleave -d ' ' -i '**patt' -o '**rows' retroinv.pat > analysis.4

assemble analysis.[1-4] > temp
cleave -d ' ' -i '**rows' -o '**rows' temp > analysis.out

# Finally, clean up some temporary files:

rm [PRI][0-9].pat [PRI]1[01].pat RI[0-9]*.pat temp.pat
rm analysis.[1-4] temp temp.pc score.tmp

There are a few subtleties and problems that deserve mention about our rowfind script. In general, shorter patterns are easier to find than longer patterns. Since row statements tend to be unique after the first 4 or 5 notes, it is preferable to clip the row patterns used as templates. Reducing the length of the templates can lead to "false hits" -- but these tend to be infrequent and are easily recognized.

Applied to an entire multi-part score, rowfind may miss concurrent row statements due to interposed notes appearing in an irrelevant instrument or part. This problem can be avoided by first extracting individual parts and running rowfind on each part separately. (The results can then be amalgamated using assemble and cleave.) On the other hand, searching instruments separately can mean that row statements crossing between instruments may be missed. This problem can be addressed by extracting pairs and groups of instruments and analyzing them together.

For a complex work like Webern's Opus 24 Concerto, this strategy of analyzing both individual instruments and groups of instruments works very well.


Reprise

In this chapter we have discussed several tools related to set theory analysis. These include the pc (pitch-class) command, the pcset command (for identifying set-forms), and the reihe command (for generating set variants).

We have seen how general tools like context can be used to carry out segmentation of some score. Similarly, we have seen how the patt command can be used to identify tone-row statements.

Two scripts were described in this chapter: matrix and rowfind. These demonstrated how the tools may be coordinated to carry out various automated processes.

This chapter has only scratched the surface regarding the types of pertinent serial-related manipulations that might be pursued. For example, much more sophisticated approaches to segmentation can be created by using some of the layer techniques described in the next Chapter. Similarly, the pattern searches could easily be expanded to look at other parameters typical of "complete serialism" -- such as durations, dynamics, articulation marks, and so on.
